- 产品描述
-
Product Feature
1.Average gluing speed should be 8000-10000pcs hour.fast speed,which improves productivity greatly.
2.Automatic paper supply,automatic glue coating,automatic folding,automatic correction,automatic counting,only two people can complete the whole process.
3.Adopt suction belt feeding method,simple structure,fast speed,accurate feeding.
4.Adopted tooth nail belt paper feeding method,paper feeding accurate:And with the function of secondary indentation,the carton folding is more accurate.
5.It has the function of secondary rectifying deviation,eliminating the big and small mouth and reducing the reject rate.
6.With differential speed correction adjustment function,completely eliminate scissor forks,folding more accurate.
7.Collection section automatic counting,shaping,piling into the code,the whole code output,speed is fast .
8.Can combination of automatic packaging binding machine line,high speed,saving labor.
Product parameter
Model WB-2400 WB-2600 WB-2800 Max.Cardboard 900x2200mm 1200x2400mm 1200x2600mm Min.Cardboard 300x800mm 300x800mm 300x800mm Overall dimensions 12800x2850x2250mm 12800x3050x2250mm 12800x3250x2250mm Power Required 10kw 11kw 12kw Speed 120-180cartons/min Finished product
In today's fast-paced packaging production world, the AFG High-Speed Automatic Folder Gluer Machine, with its superior performance, has become a valuable aid for many companies in improving production efficiency and quality.
High-Speed and Stable Operation
The AFG High-Speed Automatic Folder Gluer Machine boasts impressive operating speeds, capable of completing a large number of folder gluing jobs per hour. Its advanced transmission system and precise mechanical design ensure stable operation even at high speeds. Its unique feeder system delivers paper quickly and accurately, effectively reducing problems such as paper jams, significantly improving production efficiency and meeting the demands of large-scale packaging production.
Precise Gluing
This folder gluer utilizes a high-precision gluing device that precisely controls the amount and placement of glue applied to each box, ensuring a perfect fit for both standard straight-line boxes and complex, custom-shaped boxes. Its advanced pressing mechanism ensures even force during gluing, ensuring a secure bond and effectively preventing quality issues such as debonding, ensuring every box meets high-quality standards.
Intelligent Operation Experience
The AFG High-Speed Automatic Folder Gluer Machine is equipped with an advanced intelligent control system and features a simple and intuitive user interface. Operators can easily set various parameters, such as gluing speed and glue application amount, through the touchscreen. The machine also features automatic detection and alarm functions. If an abnormality occurs, it promptly issues an alarm and displays fault information, enabling quick troubleshooting and resolution, reducing the need for specialized technical expertise.
Wide Applicability
This folder gluer is suitable for a wide variety of paper and paperboard types, from cardboard and corrugated paper to boxes of varying sizes and shapes. With simple adjustments and replacement of accessories, it can meet the diverse needs of different customers, providing significant convenience for packaging companies.
With its high speed and stability, precise process, intelligent operation, and wide applicability, the AFG High-Speed Automatic Folder Gluer Machine has become an indispensable and efficient production equipment for the packaging industry, helping companies stand out in the fiercely competitive market.
