Product characteristics
1.Air suction paper feeding more accurate.
2.Carton forming speed is fast.
3.Secondary indentation to make origami more accurate.
4.Good size control and reduced waste.
5.Second correction, completely eliminate the scissors port.
6.The nailing department is well controlled and reduces waste.
7.Accurate counting.
8.The beater makes the carton shape well.
9.Bundle out the pile accurately and neatly.
10.Secondary indentation: The carton indentation paper is fixed for the second time to make the origami position more accurate, so that the carton is not broken and the crease is beautiful.
11.Secondary rectification part: completely eliminate the size of the mouth, the pass rate is higher.
12.Nail part: pneumatically control the carton before and after nailing to eliminate the scissors.
13.Receiving and shaping department: The finished box is automatically counted, the shaping is piled up neatly, and the code is output.
14.Packing Department: Packing speed is fast and beautiful.
Product parameter
Model 2600 2800 Max. cardboard 1200x2200mm 1200x2400mm Min. cardboard 300x850mm 300 x 850mm Installation area 3800x14000mm 4000x14000mm Power required 14kw 14kw Stick speed 150 pcs/min Maximum gluing speed 220 pcs/min Nail box speed 80 pcs/min Total length of production line 14m
